UCC2 to SPA2 6th axis cable
| Part number | Length |
| P-CA82-0013 | 360 mm (14.17 in) |
This straight Ethernet cable has RJ45 type plugs that are connected pin-to-pin at each end. Each 6th axis installation requires one of these cables for the additional signal communications between units.
End 'A' and 'B' | Wire |
|---|---|
1 | Orange / white |
9 | Orange |
10 | Green / white |
11 | Blue |
12 | Blue / white |
13 | Green |
14 | Brown / white |
15 | Brown |
