PL7T probe interface cable
| Cable name | Part number | Length |
| PL7T | A-1029-0166 | 3.1 m (122.1 in) |
This straight cable has a 5-pin DIN plug at each end. It is a probe interface cable used to connect manual probe heads to the interface or OEM extension.
| End 'A' | Wire | End 'B' | Signal |
|---|---|---|---|
| 1 | Red | 1 | Head LED cathode |
| 2 and shell | Screen | 2 and shell | Screen |
| 3 | Yellow | 3 | Head LED anode |
| 4 | Blue | 4 | Probe circuit |
| 5 | Green | 5 | Probe circuit |
