SPA2 to UCC2 emergency stop cable
| Part number | Length |
| A-5121-0062 | 750 mm (29.53 in) |
This straight cable has a 9-pin D-type plug at end 'A' and a 25-pin D-type plug at end 'B'. It is used to relay emergency stop (E-STOP) signals between the SPA2 servo power amplifier and UCC2 universal controller.
End 'A' | End 'B' | Signal |
|---|---|---|
3 | 25 | Ground 24 V |
6 | 6 | E-STOP 'A' |
7 | 7 | E-STOP 'B' |
8 | 4 | Engage |
9 | 3 | E-STOP 'C' |
Shell | Screen | Shell |
