PL172 PHC10-3 three-way linking cable
| Cable name | Part number |
| PL172 | A-5684-1000 |
This cable is used to combine a multiwire system with a standard touch-trigger probe system using the PHC10-3 7-pin DIN raw probe input connector, without the need for an IS1-2 interface selector to route signals.
End 'B' | Wire | End 'A' and 'C' |
|---|---|---|
1 | White / brown stripe | C1 |
3 | Black (cable 2) | A4 - Black (cable 1) C3 |
4 | Red | C4 |
5 | Orange | C5 |
6 | Grey | C6 |
7 | White | C7 |
8 | White / black stripe | C8 |
9 | Co-axial outer | C9 |
10 | Co-axial core | C10 |
11 | Violet | C11 |
12 | Blue | C12 |
14 | Green | C14 |
15 | Yellow | C15 |
A5 - Brown (cable 1) | ||
| C13 - Brown (cable 2) |
