PL37 probe signal cable
| Cable name | Part number | Length |
| PL37 | A-1054-0003 | 500 mm (19.69 in) |
This straight cable has in-line 7-pin DIN plugs at each end. It electrically connects Renishaw probe interfaces and probe head controllers and passes SSR (solid state relay) signals between them.
End 'A' and 'B' | Wire | Signal |
|---|---|---|
1 | Yellow | LED cathode |
2 and shell | Screen | Screen |
3 | Green | LED anode |
4 | Red | Probe return |
5 | Blue | Probe signal |
6 | Black | Inhibit return |
7 | White | Inhibit signal |
