PL107 PHS1 / PHS-2 overtravel cable
| Cable name | Part number | Length |
| PL107 | A-2150-0484 | 30 m (1181.1 in) |
This straight cable requires a 15-pin high-density D-type socket (NOT supplied) at end ‘A' and a 15-pin high-density D-type plug (NOT supplied) at end ‘B'.
It is used for the overtravel signal between the PHS1 / PHS-2 servo-positioning head and the PHS PC card.
End 'A' and 'B' | Wire |
|---|---|
Pins 1 to 13 not used | - |
14 | White |
15 | Brown |
Shell | Screen |
NOTE: Plug contact pin crimp.
