PL82V video compatible probe cable
| Cable name | Part number | Length |
| PL82V | A-1016-7648 | 5 m (196.85 in) |
This straight cable has a 12-pin round Hirose-type plug at end ‘A' and a 15-pin high-density D-type plug at end ‘B'. It is used to link (the now obsolete) VP2 video cameras to the VPI 2 video probe interface or to link shank mounted SP600 version scanning probes to AC1 or AC2 cards. The ‘V' suffix on cable markers indicate video system compatibility, signal details are shown below for both applications.
| End 'A' | Wire | End 'B' | MIH-SI signals | VP2 probe signals | SP600 probe signals |
|---|---|---|---|---|---|
1 | Brown | 1 | + supply | Reference | Reference |
2 | Blue / white | 12 | LED anode | Probe sense return | 0 V |
3 | Green | 3 | Head clock | Identification 0 V | + 5 V |
4 | Violet | 4 | Head data | n/a | Y axis |
5 | Yellow | 5 | Head data | n/a | Z axis |
6 | Red | 6 | Ground | + 12 V | + 12 V |
7 | Blue | 7 | LED cathode | Illumination supply | - 12 V |
8 | White | 8 | n/a | Identification | Probe output |
9 | Orange | 11 | n/a | n/a | X axis |
10 | Grey | 2 | Head clock | n/a | n/a |
11 | Coaxial screen | 9 | Probe | Video 0 V | n/a |
12 | Coaxial inner | 10 | Ground | Video output | 0 V power |
- | - | 13 | n/a | n/a | n/a |
- | - | 14 | n/a | n/a | n/a |
- | - | 15 | n/a | n/a | n/a |
Shell | Screen | Shell | Ground | Ground | Ground |
