PL112 PICS adaptor cable
| Cable name | Part number | Length |
| PL112 | A-2172-0004 | 1.2 m (47.24 in) |
This straight three-way adaptor cable has a 26-pin high-density D-type socket at end ‘A', then branches out to a 9-pin D-plug at end ‘B' and a 9-pin D-socket at end ‘C'. It electrically connects and adapts PICS signals for Renishaw or equivalent counter cards.
End 'A' | End 'B' | End 'C' | Wire | Signal |
|---|---|---|---|---|
1 | 1 | - | Red | Stop (out) |
2 | 2 | - | Blue | PPOFF (out) |
3 | 3 | - | Green | 0 V (out) |
4 | 4 | - | Yellow | + 5 V (out) |
5 | 5 | - | White | SYNC (out) |
6 | 6 | - | Black | HALT (out) |
7 | 7 | - | Brown | PDAMP (out) |
8 | 8 | - | Violet | LEDOFF (out) |
9 | 9 | - | Orange | READ (out) |
10 | - | 9 | Orange | Probe return |
17 | - | - | - | Overtravel return |
18 | - | - | - | Overtravel |
19 | - | 8 | Violet | LEDOFF (in) |
20 | - | 7 | Brown | PDAMP (in) |
21 | - | 6 | Black | 150 Ohm pull up resistor |
22 | - | 5 | White | Probe signal |
23 | - | 4 | Yellow | LED anode (in) |
24 | - | 3 | Green | 0 V (in) |
25 | - | 2 | Blue | PPOFF ( in) |
26 | - | 1 | Red | Stop (in) |
Shell | Shell | Shell | Screen | Screen |
NOTE: Pins 11 to 16 are not connected.
