PL63, PL64 and PL65 cables for the SCR200 rack
| Cable name | Part number | Length |
| PL63 | A-1016-7630 | 5 m (196.85 in) |
| PL64 | A-1016-7631 | 10 m (393.7 in) |
| PL65 | A-1016-7632 | 20 m (787.4 in) |
These straight cables have in-line 6-pin mini DIN plugs at each end and are used to electrically connect SCR200 racks to PI 200 probe interfaces used with TP200 probes.
End 'A' and 'B' | Wire | Signal |
|---|---|---|
1 | Red | Remote set |
2 | Blue | Error |
3 | Green | Inhibit |
4 | Yellow | Power |
5 | White | 0 V |
6 | Black | n/a |
Shell | Shell | Screen |
