MCU connector (9W 'D' plug)
A 9W 'D' plug is provided for direct connection of the MCU5-2, MCU W-2 and MCUlite-2 joysticks.
| Pin number | Function |
|---|---|
1 | Ground |
2 | RX_B |
3 | RX_A |
4 | TX_A |
5 | Reserved |
6 | +12 V |
7 | TX_B |
8 | E-STOP_B |
9 | E-STOP_A |
Shell | Screen |
NOTE: Replacement 5 m MCU cable part number for joysticks: A-1016-8098.
