Descargas de encóder incremental QUANTiC™

Fichas técnicas

• Data sheet: QUANTiC™ series encoder system [en]


  Data sheet: QUANTiC™ series encoder system

  The QUANTiC ™ encoder series provides robust incremental position measurement for linear, partial arc and rotary systems with excellent metrology and wide installation tolerances. This reduces or eliminates the need for mounting adjustment during the installation process.

  [1.4MB]
• Data sheet: RTLC incremental linear scale [en]


  Data sheet: RTLC incremental linear scale

  RTLC linear encoder tape scale from Renishaw combines ±5 μm/m accuracy with the ruggedness of stainless steel. Two versions are available; self-adhesive RTLC-S and RTLC for use with the revolutionary FASTRACK track system from Renishaw.

  [1.1MB]
• Data sheet: RKLC incremental linear scale [en]


  Data sheet: RKLC incremental linear scale

  RKLC is a robust, 6 mm wide stainless steel encoder tape scale with a thickness of 0.15 mm. This allows the scale, when rigidly fixed to a machine axis, to become ‘mastered’ to the machine substrate, matching its thermal expansion coefficient and behaviour. Differential movement between the scale and the machine is thus minimised, improving the metrological performance that can be achieved with simple thermal system compensation.

  [644kB]
• Data sheet: RKL scale for partial arc applications [en]


  Data sheet: RKL scale for partial arc applications

  Measuring a partial arc of rotation is made easy with Renishaw’s flexible RKL encoder scales. The flexible nature of the small cross-sectional area of these scales allows them to be wrapped around a drum, shaft or arc with a minimum radius of 26 mm. RKL scale is compatible with Renishaw’s QUANTiC™, VIONiC™, TONiC™, ATOM DX™, ATOM™ and RESOLUTE™ readheads providing a partial arc solution for a wide range of applications.

  [978kB]
• Data sheet: RESM rotary scale [en]


  Data sheet: RESM rotary scale

  The RESM is a one-piece stain less steel ring with 20 μm scale marked directly onto the periphery, featuring the IN-TRAC™ auto-phase optical reference mark.

  [863kB]
• Data sheet: Advanced Diagnostic Tool ADTi-100 [en]


  Data sheet: Advanced Diagnostic Tool ADTi-100

  The ADTi-100 (A-6195-0100) is used in conjunction with a PC* running the ADT View software†. It provides comprehensive real-time feedback from QUANTiC™, VIONiC™ and ATOM DX™ encoders, aiding installation and diagnostics, as well as allowing system optimisation.

  [409kB]
